Additional information
| Power | 30W, 50w 70w 100w |
|---|---|
| Efficiency | PC:>1001m/w, Glass:>140lm/w |
| Lumen output | ≥3000lm, 5000Im, 7000lm, ≥10000lm, 4200lm, 7000lm, 9800lm, ≥14000lm |
| Led chips | Philips lumileds 3030 |
| CRI | >80 |
| Life span | 50, 000hrs at Ta=25deg, L70/B10 |
| Color Temperature | 2700K-6500K |
| Optic lens | PC Lenses |
| Driver | Philips Xi-EP series ( Meanwell/Inventronic/Osam upon request ) |
| Input Voltage | 100-305 VAC (Depending on driver model) 47-63 Hz |
| Power factor | >95 |
| THD | <10 |
| Protection level | GLASS I |
| SPD | 10KV (optional 20KV or other) |
| Finish | powder coating |
| Housing color | RAL 7035, RAL7024 (others upon request ) |
| IP Rating | IP66 |
| IK Rating | IK10 |
| Mounting | Single post top [10-18 ft. Mounting heights], Single arm post top [18-22 ft. Mounting heights], Twin arm post top [18-30 ft. Mounting heights], Large wall mount [10-18 ft. Mounting heights] |
| Working Temperature | -30°C – + 65°C |
| Warranty | 5 years |
| Applications | BUILDING SURROUNDS, PARKS PROMENADES & PATHWAYS, PEDESTRIAN AREAS & CYCLE PATHS, URBAN & RESIDENTIAL STREETS |
| Housing | |
| Diffuser |
